2.2. Function keys F1 - F4
These keys are located right below the display. The functions attributed to them are indicated on the
display by icons.
As the operator advances in the handling, the functions of the keys are automatically reattributed to
correspond to the circumstance and availability of the bar feed system.
2.3. Left / right / up / down keys
These keys allow entering values (bar stock diameter, part length, etc.) or parameters.
2.4. Emergency stop button
When a dangerous situation arises, pressing the emergency stop switch interrupts immediately all bar
feed system and lathe functions (if interface is wired accordingly).
To cancel the alarm, release the switch by rotating its red knob counter-clockwise, then press [STOP].
2.5. MODE buttons
2.5.1. MENU key
The MENU key allows access to the main menu, where the parameters concerning the production, the
interface and the general settings of the barfeed can be reviewed and changed.
2.5.2. STOP key
The STOP key allows interrupting the sequence under way.
Important: the automatic cycle of the lathe must first be interrupted.
By pressing the STOP key, allows to exit the setting mode, regardless of the level reached, and to return
to the work screen.
The STOP key is not an emergency button, and cannot be interpreted as such. For
emergency cases, always use the emergency button located on the top of the
remote control.
2.5.3. HELP key
The HELP key displays useful information about the software version, the firmware of the critical
components, the current status of the inputs and outputs of the system.
