CHAPTER 7: OPERATION
Switch between normal feed rate and
slow feed rate (only in manual mode) for
added positioning accuracy
Validate
Cancel
Confirm. In setup mode, the button
must be hold for 3 seconds to
validate the change.
Start sequence
Enter the loading table calibration mode
Rise the loading table (in calibration
mode)
Automatic Top-Cut positioning in manual
mode (picture may be reversed)
Teach data
Offset correction
Increment data in offset correction mode
Decrement data in offset correction mode
Lower the loading table (in calibration mode)
