3.

PROGRAMMING EXAMPLE

MAIN PROGRAM
N... "M" CODE "LATHE IN AUTOMATIC
CYCLE"
N... SPINDLE STOP
N... COOLANT OFF
N... TURRET TO FEED IN POSITION
N... COLLET OPEN
N... TURRET TO FEED OUT POSITION
N... END OF BAR CHECK
(PROGRAM JUMP) >
N... CLOSE COLLET
N... CLEAR TURRET
N...
PART PROGRAM
N... X, Z, G, F, T, S, M, ...
N... MACHINE PART
N... PARTS CATCHER IN (IF AVAILABLE)
N... CUT OFF
N... PARTS CATCHER OFF (IF
AVAILABLE)
N...
N...
N... X, Z, G, F, T, S, M, ...
N...
N... END OF PROGRAM (LOOP)
Important: The above is an example only. Programming may change according to the interface
between the lathe and the bar feed.
QUICK LOAD SERVO III MI
> SUB-PROGRAM
N... TURRET HOME
... "M"CODE (DWELL/LOAD)
N... CLOSE COLLET
N... START SPINDLE
N... COLLANT ON
N... TOP CUT MATERIAL
N...
N...
N... END OF SUB-PROGRAM
< (RETURN TO MAIN PROGRAM)
