LNS QUICK LOAD SERVO III MI Instruction Manual page 80

7-4
2.1. Display
The liquid crystal display with touchscreen function provides the operator with all the necessary data, both
for handling the bar feed system and for maintenance.
General aspect
Current
barfeed
sequence
Information
screen on
current
action or
mode
Current
torque
applied
Current
feeding axis
position
The icons available are the following:
Icon
Referencing position
Switch to automatic mode
Stop after machining one bar stock
Switch to manual mode
Pusher forward
reversed)
Pusher reverse
reversed)
QUICK LOAD SERVO III MI
Signification
(picture may be
(picture may be
CHAPTER 7: OPERATION
Available functions, depending on
the current situation
Icon Signification
Set a new value
Escape
Return to previous menu
Jump to next menu
Move the loading table up + load a new bar
into the loading table
Move the loading table down
Current status
or working
mode
Unit system
(mm or inch)
Bar diameter
and feedout
length
Clamping
device status
Information line
on current
action
