1.

STRUCTURE

This manual consists of various chapters, each containing several points, paragraphs, etc. Lists may be
contained in paragraphs.
•
The page number is indicated in the top outer corner of the page.
•
The chapter number and title are indicated in the top inner corner of the page.
•
The model of the bar feed system is indicated in the bottom right-hand corner of the page.
1.1. Cross-references
Each chapter generally contains all of the information related to the description and settings of the
devices and elements represented therein.
Therefore, if a setting must be made while you are handling the system, please refer to the chapter on the
device to be set, for example: (see chapter *) or (see point *).
1.2. Captions
Whenever possible, the reference numbers contained in the instruction manual are shown with the LNS
ordering number of the indicated element.
To make it easier to place an order of supplies, a form has been included in the annex at the end of this
manual.
1.3. Symbols and terminology
This sign recommends following the directions very closely avoiding causing an
incident that could result in injury, damage to the equipment, or data loss.
This sign indicates that safety measures must be taken to avoid possible electrical
shocks or mishaps.
The notes stress interesting points or comments, and provide useful advice for
optimal system operation.
This sign points out an advice about environmental protection.
