CHAPTER 4: ELECTRICS
1.2. Layout of the electrical elements on the bar feed system
SQ11
SQ1
Designation Reference no.
A
B 4.068/4.074
C
QS1
M1
M2
SQ1
SQ2
SQ3 44.0072
SQ4
SQ5
SQ10
SQ11
SQ12 4.291/4.292
SQ10
SQ12
Description
4.972 Remote control (not shown here)
24 pin connector with cover (not shown here)
- Control cabinet
4.242 Main disconnect switch
4.569 Servo motor
4.307 Motor for diameter adjustment
4.484 Loading table in lower position
4.484 Loading table in upper position
Measuring cell
4.391 Proximity switch for diameter adjustment
4.391 Proximity switch for pusher in home position
4.284 Main access cover safety switch
4.277 Magazine grid cover safety switch
Retraction system in position switch (incl. key)
M1
SQ5
C
QS1
SQ2
SQ4
SQ3
M2
