CHAPTER 4: ELECTRICS
1.4.7. PLC inputs / outputs
Inputs
Input Des.
I0 K8 Safety relay
I1 SP1 Air pressure switch
I2 SQ10 Main cover safety
I3 SQ11 Loading magazine grid safety
I4 SQ12 Retraction safety switch
I5 - Not in use
I6 - Not in use
I7 - Not in use
I8 SQ1 Loading table in lower position
I9 SQ2 Loading table in upper position
I10 SQ3 Measuring cell
I11 SQ4 Diameter adjustment
I12 SQ5 Pusher in home position
I13 SQ30 Loading magazine empty (option)
I14 SQ31 Telescopic pusher (option)
I15 - Not in use
Not in use
I16 -
I17 - Not in use
Not in use
I18 -
I19 - Not in use
Not in use
I20 -
I21 - Not in use
Not in use
I22 -
I23 - Not in use
Interface
I24 A1 Clamping device signal
I25 A2 Lathe in auto cycle
I26 A3 Feed order
I27 A4 Push order
I28 A.. Programmable interface input
I29 A.. Programmable interface input
I30 A.. Programmable interface input
I31 A.. Programmable interface input
Description
Outputs
Output Des.
O32 YV1A Lower loading table
O33 YV1B Raise loading table
O34 KA1 Motor M2 up
O35 KA2 Motor M2 down
O36 SON Servo motor ON
O37 - Not in use
O38 YV3 Guiding profiled bar (option)
O39 - Not in use
O40 YV2 Telescopic pusher (option)
O41 - Not in use
Not in use
O42 -
O43 - Not in use
Not in use
O44 -
O45 - Not in use
Not in use
O46 -
O47 KS Start relay
Not in use
O48 -
O49 - Not in use
Not in use
O50 -
O51 - Not in use
Not in use
O52 -
O53 - Not in use
Not in use
O54 -
O55 - Not in use
Interface
Not in use
- -
- - Not in use
Not in use
- -
- - Not in use
Not in use
- -
- - Not in use
Not in use
- -
- - Not in use
Description
QUICK LOAD SERVO III MI
