# alerts show current
Id Post Time
--- ----------------------
p0-90 Tue June 2 1:40:07 2015 CRITICAL HWFailure Encl=11:Fan Id=2 EVT-ENV-00004:

Removing the front bezel

3. Enter the alerts show current or alerts show current-detailed
command which displays messages indicating fan failure. A sample output is
shown.
Severity Class
-------- ---------
4. Enter the enclosure show fans command to check the status of each fan.
Record the failed fan. A sample output is shown. In the output below the Level
column indicates the RPM of the fan as low, medium, and high. The Status
column indicates the status as OK, Unavailable, and Failed.
# enclosure show fans
Enclosure Description
--------- --------------------
11 Cooling module fan 1
Cooling module fan 2
Cooling module fan 3
Power module A fan 1
Power module A fan 2
Power module B fan 1
Power module B fan 2
--------- --------------------
Note
You must remove the shelf's front bezel to gain access to the internal components.
The bezel is required for EMI compliance when the instrument is powered up. Remove
it only to replace or add disks or fans.
Refer to Figure 17 on page 37 while performing the procedure that follows.
Procedure
1. If the bezel has a lock, insert the key that shipped with your enclosure into the
lock, and turn the key to unlock the bezel.
2. Press the two latch buttons on the bezel surface to release the bezel from the
cabinet.
3. Pull the bezel off the cabinet and put it on a clean, static-free surface.
Figure 73 Removing the front bezel
Removing and Replacing FRUs
Object Message
----------- -----------
Cooling module fan 2
has failed.
Level Status
----- ------
low OK
low FAILED
low OK
low OK
low OK
low OK
low OK
----- ------

Removing the front bezel
