Figure 137 Sliding the shelf chassis into the rails
Note
You may need to release sagging tension on the shelf by pulling the lift arms and
tray up slightly.
4. Unlock the casters by lifting up on the locking tabs and carefully slide the shelf
into the cabinet as far as the lift will allow.
Figure 138 Unlocking the casters
CL5424
Removing and Replacing FRUs
Installing the shelf onto the rails
CL5431
