Sliding The Shelf Chassis Into The Rails; Unlocking The Casters - EMC Data Domain DS60 Hardware Manual

Figure 6 Sliding the shelf chassis into the rails
Note
You may need to release sagging tension on the shelf by pulling the lift arms and
tray up slightly.
4. Unlock the casters by lifting up on the locking tabs and carefully slide the shelf
into the cabinet as far as the lift will allow.
Figure 7 Unlocking the casters
CL5424
Shelf Installation and Removal
Installing the shelf onto the rails
CL5431
29
