Figure 127 Pulling the chassis out (two shoulder screw configuration)
CAUTION
Do not attempt to remove a populated shelf without a mechanical lift.
If the shelf that you are removing is 28U (49 inches) or more above floor
level, you need to use the conversion and support table kits from Alum-A-
Lift as described in Step 2.
Note
Instructions for the Alum-A-Lift and the conversion kit are included in the lift
kit.
Figure 128 Reconfiguring the Alum-A-Lift with the conversion kit
Removing and Replacing FRUs
Removing a shelf from the cabinet
147
