BS86DH12C
High Voltage Touch A/D Flash MCU with HVIO

D.C. Electrical Characteristics

For data in the following tables, note that factors such as oscillator type, operating voltage, operating
frequency, pin load conditions, temperature and program instruction type, can all exert an influence
on the measured values.

Operating Voltage Characteristics

Symbol Parameter
Operating Voltage – HIRC
V
DD
Operating Voltage – LIRC
Operating Voltage – LXT

Operating Current Characteristics

Symbol Parameter
SLOW Mode – LIRC
SLOW Mode – LXT
I
DD
FAST Mode – HIRC
Note: When using the characteristic table data, the following notes should be taken into consideration:
1. Any digital input is set in a non-floating condition.
2. All measurements are taken under conditions of no load and with all peripherals in an off state.
3. There are no DC current paths.
4. All Operating Current values are measured using a continuous NOP instruction program loop.
Rev. 1.00
Test Conditions
f =f =8MHz
SYS HIRC
f =f =12MHz
SYS HIRC
f =f =16MHz
SYS HIRC
f =f =32kHz
SYS LIRC
f =f =32.768kHz
SYS LXT
Test Conditions
V Conditions
DD
f =f =32kHz, LDO current
SYS LIRC
5V
consumption included
f =f =32768Hz, LDO current
SYS LXT
5V
consumption included
f =f =8MHz, LDO current
SYS HIRC
consumption included
f =f =12MHz, LDO current
SYS HIRC
5V
consumption included
f =f =16MHz, LDO current
SYS HIRC
consumption included
15
Ta=25°C
Min. Typ. Max. Unit
4.5 — 5.5
4.5 — 5.5 V
4.5 — 5.5
4.5 — 5.5 V
4.5 — 5.5 V
Ta=25°C
Min. Typ. Max. Unit
— 180 200 μA
— 180 200 μA
— 1.6 2.4
— 2.4 3.6 mA
— 6.0 9.0
October 26, 2018
