BS86DH12C
High Voltage Touch A/D Flash MCU with HVIO
Counter Value
CCRP
CCRA
PTON
PTPAU
PTPOL
CCRA Int.
Flag PTMAF
CCRP Int.
Flag PTMPF
PTM O/P Pin
(PTOC=1)
PTM O/P Pin
(PTOC=0)
PWM Duty Cycle
set by CCRA
Note: 1. The counter is cleared by CCRP
2. A counter clear sets the PWM Period
3. The internal PWM function continues running even when PTIO[1:0]=00 or 01
4. The PTCCLR bit has no influence on PWM operation
Rev. 1.00
Counter cleared by
CCRP
Pause
PWM Period set by CCRP
PWM Output Mode
99
PTM [1:0] = 10
Counter Reset when
PTON returns high
Counter Stop if
Resume
PTON bit low
PWM resumes
operation
Output controlled by other
Output Inverts
pin-shared function
When PTPOL = 1
October 26, 2018
Time
