• PTMAL Register
Bit 7
Name D7
R/W R/W
POR 0
Bit 7~0 D7~D0: PTM CCRA Low Byte Register bit 7 ~ bit 0
PTM 10-bit CCRA bit 7 ~ bit 0
• PTMAH Register
Bit 7
Name —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 D9~D8: PTM CCRA High Byte Register bit 1 ~ bit 0
PTM 10-bit CCRA bit 9 ~ bit 8
• PTMRPL Register
Bit 7
Name PTRP7
R/W R/W
POR 0
Bit 7~0 PTRP7~PTRP0: PTM CCRP Low Byte Register bit 7 ~ bit 0
PTM 10-bit CCRP bit 7 ~ bit 0
• PTMRPH Register
Bit 7
Name —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 PTRP9~PTRP8: PTM CCRP High Byte Register bit 1 ~ bit 0
PTM 10-bit CCRP bit 9 ~ bit 8
