BS86DH12C
High Voltage Touch A/D Flash MCU with HVIO
• PCS0 Register
Bit 7
Name PCS07
R/W R/W
POR 0
Bit 7~6 PCS07~PCS06: PC3 pin-shared function selection
00: PC3
01: CTP0
10: SDA
11: TX
Bit 5~4 PCS05~PCS04: PC2 pin-shared function selection
00: PC2
01: CTP1
10: SCL
11: RX
Bit 3~2 PCS03~PCS02: PC1 pin-shared function selection
00: PC1/INT
01: PTPB
10: OVPI1
11: KEY12
Bit 1~0 PCS01~PCS00: PC0 pin-shared function selection
00: PC0
01: PTP
10: OVPI0
11: KEY11
• IFS0 Register
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5~4 SDAPS1~SDAPS0: SDA input source pin selection
00: PB3
01: PB3
10: PC3
11: PA3
Bit 3~2 SCLPS1~SCLPS0: SCL input source pin selection
00: PB2
01: PB2
10: PC2
11: PA1
Bit 1~0 RXPS1~RXPS0: RX input source pin selection
00: PB0
01: PB0
10: PC2
11: PA0
Rev. 1.00
6 5 4
PCS06 PCS05 PCS04
R/W R/W R/W
0 0 0
6 5 4
— SDAPS1 SDAPS0
— R/W R/W
— 0 0
71
3 2 1
PCS03 PCS02 PCS01
R/W R/W R/W
0 0 0
3 2 1
SCLPS1 SCLPS0 RXPS1
R/W R/W R/W
0 0 0
October 26, 2018
0
PCS00
R/W
0
0
RXPS0
R/W
0
