I/O Port Sink Current Selection

The device supports different output sink current driving capability for each I/O port. With the
selection register, SLEDCOMn, specific I/O port can support two levels of the sink current driving
capability. These sink current selection bits are available when the corresponding pin is configured
as a CMOS output. Otherwise, these select bits have no effect. Users should refer to the Input/Output
Characteristics section to select the desired output sink current for different applications.
Register
Name
SLEDCOM0 PANS7
SLEDCOM1 PBNS7
SLEDCOM2
• SLEDCOM0 Register
Bit 7
Name PANS7
R/W R/W
POR 0
PANS7: PA7 sink current selection
Bit 7
0: Sink current=Level 0 (Min.)
1: Sink current=Level 1 (Max.)
PANS6: PA6 sink current selection
Bit 6
0: Sink current=Level 0 (Min.)
1: Sink current=Level 1 (Max.)
PANS5: PA5 sink current selection
Bit 5
0: Sink current=Level 0 (Min.)
1: Sink current=Level 1 (Max.)
PANS4: PA4 sink current selection
Bit 4
0: Sink current=Level 0 (Min.)
1: Sink current=Level 1 (Max.)
PANS3: PA3 sink current selection
Bit 3
0: Sink current=Level 0 (Min.)
1: Sink current=Level 1 (Max.)
Bit 2 PANS2: PA2 sink current selection
0: Sink current=Level 0 (Min.)
1: Sink current=Level 1 (Max.)
Bit 1 PANS1: PA1 sink current selection
0: Sink current=Level 0 (Min.)
1: Sink current=Level 1 (Max.)
Bit 0 PANS0: PA0 sink current selection
0: Sink current=Level 0 (Min.)
1: Sink current=Level 1 (Max.)
Rev. 1.00
High Voltage Touch A/D Flash MCU with HVIO
7 6 5
PANS6 PANS5 PANS4
PBNS6 PBNS5 PBNS4
— — PCNS5 PCNS4
I/O Port Sink Current Selection Register List
6 5
PANS6 PANS5 PANS4
R/W R/W R/W
0 0
66
Bit
4 3 2
PANS3 PANS2
PBNS3 PBNS2
PCNS3 PCNS2
4 3 2
PANS3 PANS2 PANS1
R/W R/W
0 0 0
BS86DH12C
1 0
PANS1 PANS0
PBNS1 PBNS0
PCNS1 PCNS0
1 0
PANS0
R/W R/W
0 0
