If the CTMn is in the Compare Match Output Mode or the PWM Output Mode, then
the CTMn output pin will be reset to its initial condition, as specified by the CTnOC
bit, when the CTnON bit changes from low to high.
CTnRP2~CTnRP0: CTMn CCRP 3-bit register, compared with the CTMn counter
Bit 2~0
bit 9 ~ bit 7
Comparator P match period=
0: 1024 CTMn clocks
1~7: (1~7)×128 CTMn clocks
These three bits are used to set the value on the internal CCRP 3-bit register, which
are then compared with the internal counter's highest three bits. The result of this
comparison can be selected to clear the internal counter if the CTnCCLR bit is set to
zero. Setting the CTnCCLR bit to zero ensures that a compare match with the CCRP
values will reset the internal counter. As the CCRP bits are only compared with the
highest three counter bits, the compare values exist in 128 clock cycle multiples.
Clearing all three bits to zero is in effect allowing the counter to overflow at its
maximum value.
• CTMnC1 Register
Bit 7
Name CTnM1
R/W R/W
POR 0
CTnM1~CTnM0: CTMn operating mode selection
Bit 7~6
00: Compare Match Output Mode
01: Undefined
10: PWM Output Mode
11: Timer/Counter Mode
These bits set the required operating mode for the CTMn. To ensure reliable operation
the CTMn should be switched off before any changes are made to the CTnM1 and
CTnM0 bits. In the Timer/Counter Mode, the CTMn output pin pin state is undefined.
Bit 5~4 CTnIO1~CTnIO0: CTMn external pin CTPn function selection
Compare Match Output Mode
00: No change
01: Output low
10: Output high
11: Toggle output
PWM Output Mode
00: PWM output inactive state
01: PWM output active state
10: PWM output
11: Undefined
Timer/Counter Mode
Unused
These two bits are used to determine how the CTMn external pin changes state when a
certain condition is reached. The function that these bits select depends upon in which
mode the CTMn is running.
In the Compare Match Output Mode, the CTnIO1 and CTnIO0 bits determine how the
CTMn output pin changes state when a compare match occurs from the Comparator A.
The CTMn output pin can be set to switch high, switch low or to toggle its present state
when a compare match occurs from the Comparator A. When the bits are both zero,
then no change will take place on the output. The initial value of the CTMn output pin
should be set using the CTnOC bit in the CTMnC1 register. Note that the output level
requested by the CTnIO1 and CTnIO0 bits must be different from the initial value
setup using the CTnOC bit otherwise no change will occur on the CTMn output pin
Rev. 1.00
High Voltage Touch A/D Flash MCU with HVIO
6 5 4
CTnM0 CTnIO1 CTnIO0
R/W R/W R/W
0 0 0
82
BS86DH12C
3 2 1
CTnOC CTnPOL CTnDPX CTnCCLR
R/W R/W R/W
0 0 0
October 26, 2018
0
R/W
0
