The page includes the following fields:
Object
Port
LACP
Key
Aggregation ID
Partner System ID
Partner Port
Partner Priority
Buttons
• Click Refresh to to refresh the page immediately.
• Select the Auto-refresh
seconds.
LACP port statistics
The LACP Statistics page provides an overview of LACP statistics for all ports.
NS3550-8T-2S Industrial Managed Switch User Manual
Description
The switch port number.
'Yes' means that LACP is enabled and the port link is up. 'No' means
that LACP is not enabled or that the port link is down. 'Backup' means
that the port could not join the aggregation group but will join if other
ports leave. Until that occurs, its LACP status is disabled.
The key is assigned to this port. Only ports with the same key can
aggregate together.
The aggregation ID assigned to this aggregation group.
The partner's system ID (MAC address).
The partner's port number connected to this port.
The partner's port priority.
check box to automatically refresh the page every three
