Chapter 2: Installation
Reset button pressed and released
< 5 seconds: System reboot
> 5 seconds: Factory default
LED indicators
The front panel LEDs indicate port link status, data activity, and system power.
System
LED Color
P1 Green
P2 Green
Fault Green
Ring Green
R.O. Green
Per 10/100/1000Base-T port
LED Color
LNK/ACT Green
1000 Orange
Per SFP interface
LED Color
Green
LNK/ACT
1000 Orange
16
Function
Reboots the industrial managed switch
Resets the industrial managed switch to factory default
configuration. The switch then reboots and loads the
default settings as shown below:
Default Username: admin
Default Password: admin
Default IP address: 192.168.0.100
Subnet mask: 255.255.255.0
Default Gateway: 192.168.0.254
Function
Lit: indicates that the power input 1 has power.
Lit: indicates that the power input 2 has power.
Lit: indicates that either power 1 or power 2 has no power.
Lit: indicates that the ERPS ring has been sucessfully created.
Lit: indicates that the switch has enabled ring owner.
Function
Lit: indicates the port has successfully connected to the network.
Blinking: indicates that the switch is actively sending or receiving
data over that port.
Lit: indicates the port has successfully connected to the network at
1000 Mbps.
Blinking: indicates that the switch is actively sending or receiving
data over that port.
Function
Lit: indicates the port has successfully connected to the network.
Blinking: indicates that the switch is actively sending or receiving
data over that port.
Lit: indicates the port has successfully connected to the network at
1000 Mbps.
Blinking: indicates that the switch is actively sending or receiving
data over that port.
