Object
Action
Conflict
Buttons
• Select the QCL status from the
• Select the Auto-refresh
refresh occurs every three seconds.
• Click Resolve Conflict
when the conflict status for any QCL entry is Yes.
• Click Refresh to refresh the page.
Queue policing
Configure the queue policer settings for all switch ports in the QoS Ingress Queue
Policers page.
NS3550-8T-2S Industrial Managed Switch User Manual
Description
IPv6: The QCE will match only IPV6 frames.
Indicates the classification action taken on ingress frame if parameters
configured are matched with the frame's content. Action fields are as follows:
Class: Classified QoS class. If a frame matches the QCE it will be put in the
queue.
DPL: Drop Precedence Level. If a frame matches the QCE then the DP level
will be set to the value shown under the DPL column.
DSCP: If a frame matches the QCE then DSCP will be classified with the
value shown under DSCP column.
Displays the conflict status of QCL entries when hardware resources are
shared by multiple applications. It may happen that resources required to
add a QCE may not be available, in which case it shows conflict status as
Yes, otherwise it is always No.
Conflict can be resolved by releasing the hardware resources required to
add the QCL entry by clicking the
Combined
check box to refresh the page automatically. Automatic
to release the resources required to add the QCL entry
Resolve Conflict button.
drop-down list.
