Interlogix NS3550-8T-2S User Manual page 169

The page includes the following fields:
Object
Port Members
Key Parameters
Any
EtherType
LLC
SNAP
IPv4
IPv6
NS3550-8T-2S Industrial Managed Switch User Manual
Description
Select the Port Members
QCL entry. All ports are selected by default.
Key configuration selections are as follows:
DMAC Type – Destination MAC type: possible values are unicast (UC),
multicast (MC), broadcast (BC) or Any.
SMAC – Source MAC address: 24 MS bits (OUI) or Any.
Tag – Value of Tag field can be Any, Untag, or Tag.
VID – Valid value of VLAN ID can be any value in the range 1-4095 or Any.
The user can enter either a specific value or a range of VIDs
PCP – Priority Code Point: Valid value PCP are specific (0, 1, 2, 3, 4, 5, 6, 7)
or a range (0-1, 2-3, 4-5, 6-7, 0-3, 4-7) or Any.
DEI – Drop Eligible Indicator: Selections include 0, 1, or Any.
Frame Type – Frame Type can have any of the following values: Any,
Ethernet, LLC, SNAP, IPv4, or
Note: These frame types are described below.
Allow all types of frames.
Ethernet Type –Ethernet types can have values of
Excluding 0x800(IPv4) and 0x86DD(IPv6), the default value is Any.
SSAP Address – SSAP (Source Service Access Point) selections are
to 0xFF or Any (default value).
DSAP Address – DSAP (Destination Service Access Point) selections are
0x00 to 0xFF or Any (default value).
Control Address – Control Address selections are
(default value).
PID – PID(a.k.a., Ethernet type) elections are
(default value).
Protocol – IP protocol number: (0-255,
Source IP – Specific Source IP address in value/mask format or Any. IP and
Mask are in the format x.y.z.w where x, y, z, and w are decimal numbers
between 0 and 255. When the Mask is converted to a 32-bit binary string
and read from left to right, all bits following the first zero must also be zero.
DSCP – Diffserv Code Point value (DSCP): It can be a specific value, range
of values, or Any. DSCP values are in the range of 0-63 including BE, CS1-
CS7, EF or AF11-AF43.
IP Fragment – IPv4 frame fragmented option: yes, no, any.
Sport – Source TCP/UDP port: (0-65535) or Any, specific or port range
applicable for IP protocol UDP/TCP.
Dport – Destination TCP/UDP port: (0-65535) or Any, specific or port range
applicable for IP protocol UDP/TCP.
Protocol – IP protocol number: (0-255, TCP or UDP) or Any.
Source IP – IPv6 source address: (a.b.c.d) or Any, 32 LS bits.
DSCP – Diffserv Code Point value (DSCP): It can be a specific value, range
of values, or Any. DSCP values are in the range 0-63 including BE, CS1-
CS7, EF or AF11-AF43.
Sport – Source TCP/UDP port:(0-65535) or Any, specific or port range
applicable for IP protocol UDP/TCP.
check boxes to make any port a member of the
IPv6.
0x00
TCP or UDP) or Any.
Chapter 4: Web management
0x600-0xFFFF or Any.
0x00
0x00 to 0xFF or Any
to 0xFFFF or Any
167
