Chapter 4: Web management
The page includes the following fields:
Object
ID
Interval
Variable
Sample Type
Value
Startup Alarm
Rising Threshold
Rising Index
Falling Threshold
Falling Index
Buttons
• Click Refresh to refresh the page immediately.
• Click the Auto-refresh
refresh occurs every three seconds.
• Click I<< to update the table starting from the first entry in the alarm table (i.e., the
entry with the lowest ID).
• Click >> to update the table starting with the entry after the last entry currently
displayed.
RMON event configuration
Configure the RMON Event table on the RMON Event Configuration page. The entry
index key is ID.
268
Description
Indicates the index of alarm control entry.
Indicates the interval in seconds for sampling and comparing the rising and
falling threshold.
Indicates the particular variable to be sampled
The method of sampling the selected variable and calculating the value to be
compared against the thresholds.
The value of the statistic during the last sampling period.
The alarm that may be sent when this entry is first set to valid.
Rising threshold value.
Rising event index.
Falling threshold value.
Falling event index.
check box to refresh the page automatically. Automatic
