Object
Port
Cable Status
Buttons
• Click Start to run the diagnostics.

Loop protection

This section describes the enable loop protection function that provides loop protection
to prevent broadcast loops in the industrial managed switch.
Loop protection configuration
The Loop Protection Configuration page allows the user to inspect and change the
current loop protection configurations.
NS3550-8T-2S Industrial Managed Switch User Manual
Description
The port where you are requesting cable diagnostics.
Port: Port number.
Pair: The status of the cable pair.
Length: The length (in meters) of the cable pair. The resolution is 3 meters
Chapter 4: Web management
263
