NS3550-8T-2S Industrial Managed Switch User Manual
ons
Tx Pending
Requests
Tx Timeouts
This section contains information about the state of the server and the latest
round-trip time.
Name RFC4668
Name
IP Address
-
State
-
Round-Trip
radiusAuthClie
Time
ntExtRoundTrip
Time
sions RADIUS authentication
server.
radiusAuthClientEx The number of RADIUS
tPendingRequests Access-Request packets
destined for the server that
have not yet timed out or
received a response. This
variable is incremented
when an Access-Request
is sent and decremented
due to receipt of an
Access-Accept, Access-
Reject, Access-Challenge,
timeout, or retransmission.
radiusAuthClientEx The number of
tTimeouts authentication timeouts to
the server. After a timeout,
the client may retry to the
same server, send to a
different server, or give up.
A retry to the same server
is counted as a retransmit
as well as a timeout. A
send to a different server is
counted as a Request as
well as a timeout.
Description
IP address and UDP port for the authentication
server in question.
Shows the state of the server. It takes one of
the following values:
Disabled: The selected server is disabled.
Not Ready: The server is enabled, but IP
communication is not yet up and running.
Ready: The server is enabled, IP
communication is up and running, and the
RADIUS module is ready to accept access
attempts.
Dead (X seconds left): Access attempts were
made to this server, but it did not reply within
the configured timeout. The server has
temporarily been disabled, but will get re-
enabled when the dead-time expires. The
number of seconds left before this occurs is
displayed in parentheses. This state is only
reachable when more than one server is
enabled.
The time interval (measured in milliseconds)
between the most recent Access-Reply/Access-
Challenge and the Access-Request that
matched it from the RADIUS authentication
Chapter 4: Web management
213
