Chapter 4: Web management
RADIUS accounting statistics
The statistics map closely to those specified in RFC4670 - RADIUS Accounting Client
MIB. Use the server check box to switch between the back end servers to show details
for each.
Object
Packet Counters
214
Description
RADIUS accounting server packet counter. There are five receive and four
transmit counters.
Direction Name
Responses
Rx
Rx Malformed
Responses
Rx Bad
Authenticators
Rx Unknown Types
Packets Dropped
Rx
Tx Requests
Retransmissions
Tx
Tx Pending
server. The granularity of this measurement is
100 ms. A value of 0 ms indicates that there
has yet to be round-trip communication with the
server.
RFC4670 Name Description
radiusAccClientEx The number of RADIUS
tResponses packets (valid or invalid)
received from the server.
radiusAccClientEx The number of malformed
tMalformedRespo RADIUS packets received
nses from the server.
Malformed packets
include packets with an
invalid length. Bad
authenticators or or
unknown types are not
included as malformed
access responses.
radiusAcctClientE The number of RADIUS
xtBadAuthenticato packets containing invalid
rs authenticators received
from the server.
radiusAccClientEx The number of RADIUS
tUnknownTypes packets of unknown types
that were received from
the server on the
accounting port.
radiusAccClientEx The number of RADIUS
tPacketsDropped packets that were
received from the server
on the accounting port
and dropped for some
other reason.
radiusAccClientEx The number of RADIUS
tRequests packets sent to the server.
This does not include
retransmissions.
radiusAccClientEx The number of RADIUS
tRetransmissions packets retransmitted to
the RADIUS accounting
server.
radiusAccClientEx The number of RADIUS
