Chapter 4: Web management
Object
Immediate Leave
Buttons
• Click Add New MVR VLAN
configure the new entry, and then click Save.
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
MVR status
The MVR Statistics page provides MVR status.
The page includes the following fields:
Object
VLAN ID
IGMP/MLD Queries
Received
IGMP/MLD Queries
Transmitted
IGMPv1 Joins
Received
IGMPv2/MLDv1
Reports Received
IGMPv3/MLDv2
Reports Received
IGMPv2/MLDv1
Leaves Received
Buttons
• Click Refresh to refresh the page immediately.
• Click Clear to clear all statistics counters.
150
Description
management VLAN ports.
Select the port role by clicking the Role symbol to switch the setting.
I indicates Inactive; S indicates Source; R indicates Receiver. The default
Role is Inactive.
Enable the fast leave on the port.
to add a new MVR VLAN. Specify the VID and
Description
The multicast VLAN ID.
The number of received queries for IGMP and MLD, respectively.
The number of transmitted queries for IGMP and MLD, respectively.
The number of received IGMPv1 joins.
The number of received IGMPv2 joins and MLDv1 reports, respectively.
The number of received IGMPv1 joins and MLDv2 reports, respectively.
The number of received IGMPv2 leaves and MLDv1 dones, respectively.
