Navigating the MAC table
Each page shows up to 99 entries from the MAC table, selected through the "entries
per page" input field (default is 20). When first visited, the web page will show the first
20 entries from the beginning of the MAC Table. The first entry displayed will be the
one with the lowest VLAN ID and the lowest MAC address found in the MAC Table.
The "Start from MAC address" and
starting point in the MAC Table. Clicking the
table starting from that or the closest next MAC Table match.
In addition, the two input fields will, after clicking the
of the first displayed entry, allowing for continuous refresh with the same start address.
The >> button uses the last entry of the currently displayed VLAN/MAC address pairs
as a basis for the next lookup. When the end is reached the text "no more entries" is
shown in the displayed table. Use the
The page includes the following fields:
Object
Type
VLAN
MAC Address
Port Members
Buttons
• Click Auto-refresh
every three seconds.
• Click Refresh to refresh the displayed table starting from the
VLAN input fields.
• Click Clear to flush all dynamic entries.
• Click I<< to update the table starting from the first entry in the MAC table (i.e., the
entry with the lowest VLAN ID and MAC address).
• Click >> to update the table, starting with the entry after the last entry currently
displayed.
Dynamic ARP inspection table
Entries in the Dynamic ARP Inspection Table are shown on this page. The Dynamic
ARP Inspection Table contains up to 1024 entries, and is sorted first by port, then by
VLAN ID, then by MAC address, and then by IP address.
NS3550-8T-2S Industrial Managed Switch User Manual
VLAN
I<<
Description
Indicates if the entry is a static or dynamic entry.
The VLAN ID of the entry.
The MAC address of the entry.
The ports that are members of the entry.
to refresh the page automatically. Automatic refresh occurs
input fields allow the user to select the
Refresh button updates the displayed
Refresh
button to start over.
Chapter 4: Web management
button, assume the value
MAC address and
