The page includes the following fields:
Object
MSTI
Priority
Buttons
Click
Save
to save changes.
Click
Reset
to undo any changes made locally and revert to previously saved
values.
MSTI configuration
The MSTI Configuration page permits the user to inspect and change the current STP
MSTI bridge instance priority configurations.
NS3550-8T-2S Industrial Managed Switch User Manual
Description
The bridge instance. The CIST is the default instance, which is
always active.
Controls the bridge priority. Lower numerical values have higher
priority. The bridge priority plus the MSTI instance number,
concatenated with the 6-byte MAC address of the switch, forms a
bridge identifier.
Chapter 4: Web management
123
