The page includes the following fields:
Object
Type
Speed
Wave Length(nm)
Distance(m)
Buttons
• Click Refresh to refresh the page immediately.
• Select the Auto-refresh
regular intervals.
Port mirror
Configure port mirroring on the Mirror & RMirror Configuration Table page. This function
provides the monitoring of network traffic that forwards a copy of each incoming or
outgoing packet from one port of a network switch to another port where the packet can
be studied. It enables the manager to keep close track of switch performance and alter
it if necessary.
• To debug network problems, selected traffic can be copied, or mirrored, to a mirror
port where a frame analyzer can be attached to analyze the frame flow.
• The industrial managed switch can unobtrusively mirror traffic from any port to a
monitor port. You can then attach a protocol analyzer or RMON probe to this port to
perform traffic analysis and verify connection integrity.
NS3550-8T-2S Industrial Managed Switch User Manual
Description
Displays the type of current SFP module. The possible types are:
• 1000Base-SX
• 1000Base-LX
• 100Base-FX
Displays the speed of the current SFP module. Different vendors'
SFP modules might show different speed information.
Displays the wavelength of current SFP module. Use this column to
check if the wavelength values of two nodes are matched when the
fiber connection fails.
Displays the supported distance of the current SFP module.
check box to enable an automatic refresh of the page at
