Object
IP Address
Ping Length
Buttons
• Click Start to transmit ICMP packets.
• Click New Ping
Remote IP ping test
This Remote ICMP Ping Test page allows you to issue ICMP PING packets to
troubleshoot IP connectivity issues on a special port. After clicking Test, five ICMP
packets are transmitted, and the sequence number and roundtrip time are displayed
upon reception of a reply. The page refreshes automatically until responses to all
packets are received, or until a timeout occurs.
The page includes the following fields:
NS3550-8T-2S Industrial Managed Switch User Manual
Description
The destination IP address.
The payload size of the ICMP packet. Values range from 2 bytes to 1452
bytes.
to re-start diagnostics with ping.
Chapter 4: Web management
261
