The page includes the following fields:
Basic settings
Object
Protocol Version
Bridge Priority
Forward Delay
Max Age
Maximum Hop Count
Transmit Hold Count
NS3550-8T-2S Industrial Managed Switch User Manual
Description
The STP protocol version setting. Selections are STP,
Controls the bridge priority. Lower numeric values have higher priority. The
bridge priority plus the MSTI instance number, concatenated with the 6-byte
MAC address of the switch forms a Bridge Identifier.
For MSTP operation, this is the priority of the CIST. Otherwise, this is the
priority of the STP/RSTP bridge.
The delay used by STP bridges to transition root and designated ports to
forwarding (used in STP compatible mode). Valid values are in the range of
4 to 30 seconds
Default: 15
Minimum: The higher of
Maximum: 30
The maximum age of the information transmitted by the Bridge when it is the
Root Bridge. Valid values are in the range 6 to 40 seconds.
Default: 20
Minimum: The higher of
Maximum: The lower of
This defines the initial value of remaining hops for MSTI information
generated at the boundary of an MSTI region. It defines how many bridges a
root bridge can distribute its BPDU information. Valid values are in the range
6 to 40 hops.
The number of BPDU's a bridge port can send per second. When exceeded,
transmission of the next BPDU is delayed. Valid values are in the range of
to 10 BPDU's per second.
4 or [(Max. Message Age / 2) +
6 or [2 x (Hello Time +
40 or [2 x (Forward Delay
Chapter 4: Web management
RSTP and MSTP.
1]
1)].
-1)]
