Interlogix NS3550-8T-2S User Manual page 54

Chapter 4: Web management
The page includes the following fields:
Object
SMTP Mode
SMTP Server
SMTP Port
SMTP Authentication
Authentication User Name
Authentication Password
E-mail From
E-mail Subject
E-mail 1 To / E-mail 2 To
Buttons
• Click test to send a test mail to the mail server to indicate if the account is available.
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
EEE power reduction
Configure the current EEE port settings on the EEE configuration page. EEE is a power
saving option that reduces the power usage when there is low or no traffic utilization.
EEE works by powering down circuits when there is no traffic. When a port acquires
data to be transmitted, all circuits are powered up. The time it takes to power up the
circuits is known as wakeup time. The default wakeup time is 17 us for 1G bit links and
52
Description
Controls whether or not SMTP is enabled on the switch.
Type the SMTP server name or the IP address of the SMTP server.
Set the port number of SMTP service.
SMTP authentication is enabled if selected. Authentication is required
when an email is sent.
Type the user name for the SMTP server if Authentication is Enable.
Type the password for the SMTP server if Authentication is Enable.
Type the sender's email address. This address is used for reply
emails.
Type the subject/title of the email.
Type the receiver's email address.
NS3550-8T-2S Industrial Managed Switch User Manual
