Chapter 4: Web management
Object
Egress
Remap DP0
Remap DP1
Buttons
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
DSCP classification
The DSCP Classification page permits mapping a DSCP value to a QoS Class and
DPL value.
164
Description
There are the following configurable parameters for Egress side –
Remap DP0 Controls the remapping for frames with DP level 0.
Remap DP1 Controls the remapping for frames with DP level 1.
The Configuration All with available values will assign to whole DSCP
values.
Select the DSCP value from select menu to which you want to remap. DSCP
value ranges from 0 to 63.
The Configuration All with available values will assign to whole DSCP
values.
Select the DSCP value from select menu to which you want to remap. DSCP
value ranges from 0 to 63.
