This page includes the following fields:
General settings
Object
Enable Loop
Protection
Transmission Time
Shutdown Time
Port configuration
Object
Port
Enable
Action
Tx Mode
Buttons
• Click Save to save changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
Loop protection status
The Loop Protection Status page shows the loop protection port status of the switch.
264
Description
Controls whether loop protections is enabled (as a whole).
The interval between each loop protection PDU sent on each port. Valid
values are 1 to 10 seconds.
The period (in seconds) for which a port will be kept disabled in the event
that a loop is detected and the port action shuts down the port. Valid values
are 0 to 604800 seconds (seven days). A value of zero keeps a port
disabled until the next device restart.
Description
The switch port number.
Controls loop protection enable/disable on this switch port.
Configures the action performed when a loop is detected on a port.
Selections include Shutdown
Controls if the port is actively generating loop protection PDUs or if it is just
passively looking for looped PDU's.
Port, Shutdown Port and Log
NS3550-8T-2S Industrial Managed Switch User Manual
or Log Only.
