Chapter 4: Web management
The page includes the following fields:
Object
Event Index
Log Index
LogTime
LogDescription
Buttons
• Click Refresh to refresh the page immediately.
• Click the Auto-refresh
refresh occurs every three seconds.
• Click I<< to update the table starting from the first entry in the alarm table (i.e., the
entry with the lowest ID).
• Click >> to update the table starting with the entry after the last entry currently
displayed.
RMON history configuration
Configure RMON History on the RMON History Configuration page. The entry index
key is ID.
The page includes the following fields:
Object
Delete
ID
Data Source
Interval
Buckets
Buckets Granted
270
Description
Indicates the index of the event entry.
Indicates the index of the log entry.
Indicates event log time.
Indicates the event description.
check box to refresh the page automatically. Automatic
Description
Select to delete the entry. It will be deleted during the next save.
Indicates the index of the entry. The range is from 1 to 65535.
Indicates the port ID to be monitored. If in the switch, the value must add
1000*(switch ID-1). For example, if the port is switch 3 port 5, the value is
2005.
Indicates the interval in seconds for sampling the history statistics data. The
range is from 1 to 3600, default value is 1800 seconds.
Indicates the maximum data entries associated with this history control entry
stored in RMON. The range is from 1 to 3600, default value is 50.
The number of data to be saved in the RMON.
