WLISt Subsystem
WLISt
Table 4-1 WLISt Subsystem Parameter Values
Parameter
delay_value
module_spec
bit_id
label_name
line_num_mid_screen
waveform
acquisition_spec
time_value
time_range
WLISt
Selector
:WLISt
The WLISt (Waveforms/LISting) selector is used as a part of a compound
header to access the settings normally found in the Mixed Mode menu.
Because the WLISt command is a root-level command, it will always appear
as the first element of a compound header.
The WLISt subsystem is only available when one or more state analyzers with
time tagging on are specified.
Example
OUTPUT XXX;":WLIST:XTIME 40.0E−6"
4–4
Value
real number between -2500 s and +2500 s
{1|2|3|4|5|6|7|8|9|10} (slot where master card
is installed)
integer from 0 to 31
string of up to 6 alphanumeric characters
integer from -516096 to +516096 (HP 16554A) or -1040384 to
+1040384 (HP 16555A) or -2080768 to +2080768 (HP 16555D)
string containing <acquisition_spec>{1|2}
{A|B|C|D|E|F|G|H|I|J}
real number
real number between 10 ns and 10 ks
