Figure 9-1
SCHart Subsystem Syntax Diagram
Table 9-1 SCHart Subsystem Parameter Values
Parameter
state_low_value
state_high_value
label_name
label_low_value
label_high_value
low_value
high_value
marker_type
Value
integer between ±516096 (HP 16554A), ±1040384 (HP
16555A), or ±2080768 (HP 16555D)
integer from
<state_low_value>
16554A), 1040384 (HP 16555A), or 2080768 (HP 16555D)
a string of up to 6 alphanumeric characters
32
string from 0 to 2 - 1 (#HFFFFFFFF)
string from
<label_low_value>
(#HFFFFFFFF)
32
string from 0 to 2 - 1 (#HFFFFFFFF)
32
string from low_value to 2 - 1 (#HFFFFFFFF)
{X | O | XO | TRIGger}
SCHart Subsystem
to 516096 (HP
32
to 2 - 1
9-3
