AMX Vision 2 Operation/Reference Manual page 98

Archive Service
To create a new table section click Add new Table section, select the number of rows and columns, and click
Add Table.
Add New Table Section Options
Section Name
Displayed Name
Visible to users
Edit Table
Insert Column
Delete Column
Insert Row
Delete Row
Colour
Width
User can edit this column
You can insert text into the table as a hint for when someone is adding metadata to a video. FIG. 82 displays a
new table based section and the hints.
FIG. 82 Metadata Table
88
This is the name of the section as it appears on the left side of the page and
also when editing metadata in the archive. It can be different to the Displayed
Name so that related sections appear together in the lists. For example:
• Music Video: Info
• Music Video: Credits
• Music Video: Lyrics
• TV Program: Credits
• TV Program: Synopsis
This is the name of the section as it will be displayed to a user.
Check this box if you want the section to be visible to the users. If it is not
checked then it will only be visible in the management interface.
Allows you to insert an extra column
Allows you to delete the selected column
Allows you to insert a new row
Allows you to delete the selected row
Allows you to change the color of the selected column
Allows you to define the width of the selected column
Check the box to allow the contents of the column to be edited (see example
below)
