Wiring and Device Connections
Master Server Rear Panel Connections
This section details the ports and connectors on the rear panel of the Vision
Output port
FIG. 2
Vision
Some rear panel connectors are not available with certain solutions. See the
Overview section on page 1 for information on the options included with your
solution.
LAN (RJ-45) Port
FIG. 3
LAN (RJ-45) Port
FIG. 4 describes the blink activity for the LAN 10/100/1000 Base-T RJ-45 connector and cable.
FIG. 4
LAN connector / LEDs
To prevent multicast traffic from flooding your network, use LAN port 2 as the Vision
client side multicast interface.
2
Vision
Operation/Reference Guide
2
Master server rear panel
A - Activity LED (yellow)
lights when receiving or
transmitting LAN
data packets
LAN ports
A
L
L - Link LED (green) lights when
the LAN cables are connected
and terminated correctly.
ETHERNET
Wiring and Device Connections
2
Master server.
Power connector
2
15
