STB-04 Set-Top Box

The following table lists the specifications for the STB-04 Set-Top Box (FG3100-65):
STB-04 Set-Top Box Specifications
Memory:
Power:
Front Panel LED:
Rear Panel Components:
Power connector
LAN ports
USB port
HDMI port
SPDIF port
AUDIO VISUAL port
IOIOIO port
Codecs:
Video Resolution:
Graphics Resolution:
Audio:
Operating Environment:
Dimensions (HWD):
Weight:
Included Accessories:
2
Vision Operation/Reference Guide
128MB Flash, 256MB RAM
• 5V DC at 1.5A via external power supply
• Less than 8W typical usage (external supply input voltage 100-240V AC
50-60Hz 3A max)
Power on/IR command received (Red)
1 connector port for a 5V DC at 3A power supply
1 x Ethernet 10/100 BaseT via RJ-45 shielded connector
1 Type-A USB 2.0 port for peripheral connections
1 HDMI 1.3a with HDCP and CEC port
1 S/PDIF(optical) port
1 10-way Mini-DIN for Composite video, Component (YPrPb), RGB, S-Video,
and analog audio
1 IR extender and TVI port
• MPEG-2 MP@HL
• MPEG-4 pt10 AVC/H.264 HP@L4
Up to 720p and 1080i. Displays up to 1080p.
HD graphics up to 1280x720
• Analog stereo audio out
• Stereo and Dolby 5.1 surround via S/PDIF and HDMI
• Dolby Digital+ pass through to external decoder
• Operating Temperature: 0º to 40º C (32º to 104º F)
• Storage Relative Humidity: 5% to 95% (non-condensing)
1 9/16" (4cm) H x 5 1/2" (14cm) W x 4 1/2" (11.4cm) D
0.70 lbs (0.32 kg)
• 1 Amino Universal Remote Control
• 1 Amino Configuration Keyboard (FG3100-63)
