Vision
2
Vision TDS provides multiple live Digital Video Broadcast (DVB) or MPEG channels over a standard IP
network for up to 150 users for each type of channel. See the Vision2 TDS section on page 26 for information
on setting up your Digital TV appliance. See LAN (RJ-45) Port section on page 15 for information on wiring
cables for the port.
FIG. 7 Digital TV appliance (rear panel)
Vision
This section details the ports and connectors on the rear panel of the Vision
in from Video on Demand server
Power connector
FIG. 8 Vision
Use an external 4x SAS connector to connect the SAS ports on the rear of the PowerVault Drive Array to the
SAS ports on the rear of the Archive Video on Demand server or to an additional PowerVault Drive Array.
FIG. 9 displays the rear panel of the V2-STORAGE-2400 Expansion Storage device:
FIG. 9 V2-STORAGE-2400 Expansion Storage (rear panel view)
2
Vision Operation/Reference Guide
2
TDS
2
PowerVault Drive Array Rear Panel Connections
out to additional Archive
Power switch
2
PowerVault Drive Array (rear panel view)
Wiring and Device Connections
To Client-side LAN
To Video LAN
2
PowerVault Drive Array:
19
