The following table lists the Device and Template options available in the Template Editor. These options
appear across the top of the screen.
Device and Template Options
Device
Add New Device
Delete Device
Template
Edit Template
Save Changes
Discard Changes
Delete Template
Download
Upload
Create New Template

Adding a New Device to the Device List

Adding new devices to the device list is useful since each device uses specific settings geared toward each
individual device. By adding a new device, you can create a series of unique templates with settings that work
perfectly with that specific device.
Perform these steps to add a new device to the template list:
1.
Click Add New Device. A series of options appears (FIG. 39).
FIG. 39
Add New Device options
2.
Enter the name of the device in the Name field.
3.
Select the type of device from the Type options menu. You can choose from Tablet or Amino.
4.
Select the orientation view from the Orientation menu. You can choose from Landscape or Portrait.
5.
Use the Width and Height spin boxes to set the size of the screen for the device. You can set each option
to any value between 100 and 5000.
6.
Click Create to add the device to the device list.
2
Vision Operation/Reference Guide
Select a device from the available list to view its template. Any new devices
you add appear in this list.
Click to add a new device to the template list. See Adding a New Device to the
Device List section on page 39 for more information.
Click to delete the currently selected device. You will receive a confirmation
warning before deleting the device.
Select a template from the available list. Any new templates you create appear
in this list.
Click to edit the template using the settings on the left side of the screen.
These settings are not available until you click Edit Template.
Click to save any changes you make to the template. This button is only
available after you click Edit Template.
Click to discard any changes you make to the template and return the template
to its original settings. This button is only available after you click Edit
Template.
Click to delete the currently selected template. You will receive a confirmation
warning before deleting the template.
Click to load an existing template from a local or network drive.
Click to upload a template to a local or network drive. The Template Editor
creates a.zip file with all necessary files included within it.
Click to create a new template. See the Creating a New Template section on
page 40 for more information.
