Overview

Network Switch Requirements

2
Vision requires a Gigabit layer 2/3 network switch with IGMP Snooping/Querier support. Your network
switch should have the following requirements:
Network Switch Requirements
Physical Interfaces:
Layer 2 Services:
Security:
Performance Specifications:
Switching Capacity:
Forward Rate:
Internet Protocol:
Optional:
14
RJ-45 connectors for 10Base-T, 100Base-TX, 1000Base-T with 8, 16, 24, or 48
ports.
• IGMP Snooping V1 or V2 (Not router dependant for operation)
• IGMP Querier
• Layer 2/3 switching
• Spanning Tree Protocol (STP)
• QoS
• Storm Control Broadcast and Multicast
Jumbo frame support
Non Blocking 32Gbps (16Port) - 140Gbps (48Port)
24Mpps (16Port) - 96Mpps (48Port)
IPv4 or IPv6
• VLAN support
• Web User Interface
