Adding An Unmanaged Channel; View Channels; Server Logs - AMX Vision 2 Operation/Reference Manual

Master Service
The following options appear on the Manage Channel Order page.
Manage Channel Order Options
Add Unmanaged Channel
Channel Name
Type
Channel URL
Delete Unmanaged Channel
Move Channel Up
Move Channel Down
Save Changes
Perform these steps to change the channel order:
1.
Select a channel in the list.
2.
Click Move Channel Up or Move Channel Down until the channel is in its appropriate location.
3.
Click Save Changes.

Adding an Unmanaged Channel

If you have a non-Vision
add an unmanaged channel:
1.
Click Add Unmanaged Channel. A dialog box appears (FIG. 53).
FIG. 53 Add Unmanaged Channel
2.
Enter the name of the channel in the Channel Name field.
3.
Select the type of channel from the Type options menu.
4.
Enter the URL of the channel in the Channel URL field.
5.
Click Add.

View Channels

All of the available live channels are listed under this menu entry. You can view live channels by clicking on
the channel name. The Vision
view the stream from an AVN420 encoder.

Server Logs

The log files for each server can be viewed by selected the server name under this menu entry.
FIG. 54 Event Log
54
Adds an unmanaged channel to the Channel Order list.
The name of the channel as it will appear in the Channel Order list.
The type of stream for the channel.
The URL of the video source.
Removes an unmanaged channel from the Channel Order list.
Moves the selected channel one position up in the list
Moves the selected channel position down in the list
Saves the changes to the server
2
video source, you can create an unmanaged channel for it. Perform these steps to
2
interface, server, and player do not support h.264 content, therefore, you cannot
2
Vision Operation/Reference Guide
