Video on Demand Server

The following table lists the specifications for the Vision
2
Vision Video on Demand Server Specifications
Processor:
Memory:
Storage:
Power:
Front Panel Components:
USB ports
Video connector
LCD panel
Power button
DVD-ROM
Rear Panel Components:
Video connector
Serial connector
SAS connector
USB port
LAN connectors
Rack Mount
Operating Environment:
Dimensions (HWD):
Weight:
You can use the Video on Demand server as a Master server in a single-server
installation. The Video on Demand server is limited to running only eight services at a
given time.
If you are updating an existing Video on Demand Server to use the
V2-STORAGE-EXT800 External RAID Controller and V2-STORAGE-2400 server,
you must download the newest server administrator from Dell's website
(www.dell.com) and have the latest perc6i driver prior to installing the
V2-STORAGE-EXT800 External RAID Controller.
2
Vision Operation/Reference Guide
2
Video on Demand server (FG3100-02):
® ®
1 Intel E5500 Xeon 5500 series processor
12GB Memory (12x1GB), 1333MHz Single Ranked LV RDIMMs
• 2 300GB 15K RPM SA SCSI 6Gbps 3.5in Hotplug Hard Drives
• 4 1TB 15K RPM SATA 3.5" Hot Plug Hard Drives
High Output Power Supply Non-Redundant, 870W
2 USB 2.0 ports for mouse, keyboard, or external peripheral devices
1 15-pin (female) video connector for connecting a video output device such as
a PC monitor
Displays system ID, status info, and error messages.
Press to power on server.
DVD+/-RW, SATA, INTERNAL
1 15-pin (female) video connector for connecting a video output device such as
a PC monitor
1 9-pin (male) serial connector
4 SAS connectors for connection to the archive
2 USB 2.0 ports for mouse, keyboard, or external peripheral devices
4 RJ-45 LAN ports for connecting to a network router (10/100/1000 Ethernet)
Sliding Ready™ rails with Cable Management arm
• Operating Temperature: 10º C to 35º C (50º F to 95º F)
• Storage Temperature: -40º C to 65º C (-40º F to 149º F)
• Operating Relative Humidity (non-condensing twmax=29º C): 20% to 80%
non-condensing
• Maximum Humidity Gradient: 10% per hour, operational and non-operational
conditions
• Storage Relative Humidity: 5% to 95% non-condensing (twmax=38º C)
3 3/8" (8.64cm) H x 17 7/16" (44.31cm) W x 26 13/16" (68.07cm) D
Rack Weight 57.54 lbs (26.1 kg)
