MPEG Configuration

The MPEG reflector can receive both unicast or multicast streams and output both unicast or multicast
streams. When you select the Configure Reflector from the MPEG Reflector Service Menu the following page
appears (FIG. 74).
FIG. 74 Configure Vision
The following options appear on the Reflector service configuration page:
Reflector MPEG Service Options
Service Enable
Channel Name
Source
Type
V2 Channels
URL
Destination
Stream type
Multicast options
Address
Port
TTL
2
Vision Operation/Reference Guide
2
MPEG Reflector Service
This enables the service and will begin multicasting if appropriate.
Note: You cannot edit any of the other settings while the service is enabled.
The name of the service as it appears in the playlists.
Click the appropriate option button to indicate the source type. You can choose
from Local Vision2 Channel or External Source.
The options menu provides a list of all the Producer channels in the system.
This option is only available if you select Local Vision2 Channel as the source
type.
Use the provided field to enter the URL containing an MPEG-2 or H.264 video.
This option is only available if you select External Source as the source type.
Click the appropriate option button to indicate the stream type. You should
select Multicast if you are streaming over an Intranet. Select Unicast for an
Internet stream.
These options are only available if you select Multicast as the Stream type.
The multicast address for this channel. This option is pre-configured and
cannot be changed.
The multicast port for this channel. This option is pre-configured and cannot be
changed.
The multicast TTL for this channel. This option is pre-configured and cannot be
changed.
