Recording a Video Stream

Perform these steps to record a video stream:
1.
Select Configure DVR from the Record Services menu on the left pane of the window. The Record
Service page appears (FIG. 108).
2.
Select the IP address of the network you are using from the NIC to Use options menu.
3.
Select Continuous from the Recording type options menu.
4.
Select the length of each individual recording from the Segment length options menu.
5.
Use the Keep Archives for spin box to indicate how long you want the recordings to remain in the
archive.
6.
Click Apply to save the new settings.
7.
Click the Recording Enable check box to begin recording the video stream.
If you disable a live service that is being recorded, the record service will generate an
error. You must stop the current record service, and then start and stop a second
record service to clear the error. Once the error is cleared, the record service should
function normally again. This error also occurs if you refresh your browser during a

Manual Recording.

Manual Recording
After you have configured the Record service for manual recording and have enabled recording, select
Manual Recording from the Record services menu. A video player opens with additional controls to stop and
start the recording. You can also enter the filename as it will appear in the archive while the video player is
open. The maximum supported manual recording is three hours.
The file name is not the name of the file that will be recorded, but it is the name of the
recording as displayed in the archive.
