Service Settings

FIG. 70 WMV Encoder Service Settings
The top section of the page deals with the settings for the service itself and consists of the following options:
Service Settings Options
Service Name
Encoder Type
Encoder IP Address
Username
Password
Perform these steps to configure the VBrick WMV Appliance Encoder:
1.
Select Configure Encoder from the MAX Encoder Menu. The Live Service page opens (FIG. 68).
2.
In the Service Name text box, enter the name of the service as you want it to appear in playlists.
3.
Click Apply.
4.
Select the type of encoder you want to configure from the Encoder Type options menu.
5.
Click Apply.
6.
Enter the network IP Address of the encoder in the Encoder IP Address field.
7.
In the Username text box, enter the username used to gain access to the encoder. The default username is
admin.
8.
In the Password text box, enter the password used to gain access to the encoder. The default password is
admin.
9.
Click Apply.
If you enter an incorrect IP address the system will attempt the connection for 30
seconds and then, if unsuccessful, the following message will appear at the bottom of
the page: "The encoder is not responding and is probably offline."
2
Vision Operation/Reference Guide
The name of the service as it appears in the playlists.
Use the options menu to select the type of WMV encoder you want to
configure.
The network IP Address of the encoder.
The user name required to manage the device. The default user name is
admin.
The password required to manage the device. The password is admin.
Live (WMV) Service
