DVB Service
The Configure DVB Service page consists of the following sections:

Service Settings

FIG. 76 Service settings
The top section on the page deals with the settings for the service itself and consists of the following options:
Service Options
Service Name
Apply
Use the Service Name field to enter a unique name for the DVB service. This name appears on the left pane of
the window and always refers to this specific configuration. Always click Apply after making any changes.

Tuner Hardware Settings

FIG. 77 Tuner Hardware Settings
The second section deals with the selection of the physical DVB tuner used to receive the broadcasts. The
Hardware Tuner option enables you to indicate which tuner you want to use for this service. Always click
Apply after making changes.

Scan for Channels Settings

FIG. 78 Scan for Channels Settings
The third section enables you to scan all of the frequencies used by the broadcaster and detect all of the
available TV channels.
Scan for Channels Options
Address
Port
Start
Stop
As the scan proceeds, any detected channels display in the Channel List at the bottom of the page.
The DVB system does not support the decoding of encrypted channels, therefore
encrypted channels are not added to the channel list when they are detected.
82
The name of the service as it appears in the services menu
Click to apply any change to the service name.
The address you want to scan.
The port you want to scan.
Start the process of scanning for the available TV channels.
Warning: Any existing list of channels will be deleted.
Stop the scanning process. Only use this if you wish to return later and run the
scan process again, as not all of the channels may have been detected.
2
Vision Operation/Reference Guide
