AMX Vision 2 Operation/Reference Manual page 51

The following table lists the settings available in the Template Editor.
Template Settings
Navigation:
Menu Selector Color
Render top line navigation
Color
Font Size
Vertical Text:
Render
X-Offset
Font Size
Color
Shadow Top
Shadow Bottom
Thumbnails:
Background Alpha
Columns
Rows
Corner Radius
Horizontal Gap
Vertical Gap
Horizontal Margin
Header Height
Header X-Offset
Header Y-Offset
Font Size
Header Text Color
Header Color 1
Header Color 2
Background Color
Border Width
Border Color
2
Vision Operation/Reference Guide
Use the color chart to select a color for the menu selector.
Click the check box to render the text on the navigation bar.
Use the color chart to select a color for the text on the navigation bar.
Use the spin box to indicate the size of the text on the navigation bar. You can
set any value between 1 and 255.
Click the check box to render the text on the left side bar.
Use the spin box to indicate the x-offset at which you want to align the text on
the left side bar. You can set any value between 1 and 255.
Use the spin box to indicate the size of the text on the left side bar. You can set
any value between 1 and 255.
Use the color chart to select a color for the text on the left side bar.
Use the color chart to select a color for the top shadow of the text on the left
side bar.
Use the color chart to select a color for the bottom shadow of the text on the left
side bar.
Use the spin box to indicate the alpha used to create the background gradient.
You can set any value between 0 and 255.
Use the spin box to indicate the number of columns on the navigation pages.
You can set any value between 1 and 255.
Use the spin box to indicate the number of rows on the navigation pages. You
can set any value between 1 and 255.
Use the spin box to indicate the size of the corner radius of each thumbnail.
You can set any value between 1 and 255.
Use the spin box to indicate the horizontal spacing between each thumbnail.
You can set any value between 0 and 255.
Use the spin box to indicate the vertical spacing between each thumbnail. You
can set any value between 0 and 255.
Use the spin box to indicate the margin on the left and right sides of each
thumbnail. You can set any value between 1 and 255.
Use the spin box to indicate the height of the header containing the thumbnail's
title. You can set any value between 1 and 255.
Use the spin box to indicate the x-offset at which you want to align the header's
text. You can set any value between 1 and 255.
Use the spin box to indicate the y-offset at which you want to align the header's
text. You can set any value between 1 and 255.
Use the spin box to indicate the size of the header text used for each
thumbnail. You can set any value between 1 and 255.
Use the color chart to indicate the color of the header text for each thumbnail.
Use the color chart to indicate the first header color used to create a gradient
fill.
Use the color chart to indicate the second header color used to create a
gradient fill.
Use the color chart to indicate the color of the background for each thumbnail.
Use the spin box to indicate the width of the border around each thumbnail.
You can set any value between 0 and 255.
Use the color chart to indicate the color of the border around each thumbnail.
Installation
41
